Acefast Z4 PD218W GAN Desktop Charging Adapter | Z4
218W GaN desktop power station.
TFT HD display shows the voltage and charging status of each port in real time.
Switching button between four high-power output modes.
Four ports [3xUSB-C + 1xUSB-A].
US plug.
Cable length 1.5m.
Support most fast charge protocols.
Safety certification.
Flame-retardant PC.
Product name:
ACEFAST Z4 PD218W GaN desktop power station (US).
Input:
AC110-240V, 2.5A, 50Hz/60Hz, US plug.
Output mode A:
Single port output:
USB-C1
:
3.3-21V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓5A - 100W max
.
USB-C2
:
3.3-11V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓3.25A - 65W max
.
USB-C3
:
3.3-11V⎓3A (PPS), 5V / 9V⎓3A, 12V⎓2.5A, 15V⎓2A, 20V⎓1.5A - 30W max
.
USB-A1
:
5V⎓3A, 9V⎓2A, 12V⎓1.5A - 18W max
.
Four ports output:
USB-C1 + USB-C2 + USB-C3 + USB-A1
:
100W + 65W + 30W + 18W - 213W max
.
Output mode B:
Single port output:
USB-C1
:
3.3-11V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓3.25A - 65W max
.
USB-C2
:
3.3-11V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓3.25A - 65W max
.
USB-C3
:
3.3-21V⎓3A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓3.25A - 65W max
.
USB-A1
:
5V⎓3A, 9V⎓2A, 12V⎓1.5A - 18W max
.
Four ports output:
USB-C1 + USB-C2 + USB-C3 + USB-A1
:
65W + 65W + 65W + 18W - 213W max
.
Output mode C:
Single port output:
USB-C1
:
3.3-21V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓5A - 100W max
.
USB-C2
:
3.3-21V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓5A - 100W max
.
USB-A1
:
5V⎓3A, 9V⎓2A, 12V⎓1.5A - 18W max
.
Three ports output:
USB-C1 + USB-C2 + USB-A1
:
100W + 100W + 18W - 218W max
.
Output mode D:
Single port output:
USB-C1
:
3.3-21V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓5A - 100W max
.
USB-C2
:
3.3-21V⎓5A (PPS), 5V / 9V / 12V / 15V⎓3A, 20V⎓5A - 100W max
.
USB-C3
:
3.3-11V⎓2A (PPS), 5V⎓3A, 9V⎓2A, 12V⎓1.5A - 18W max
.
Three ports output:
USB-C1 + USB-C2 + USB-C3
:
100W + 100W + 18W - 218W max
.
Total output :
218W (max).
Support fast charge protocols by ports:
USB-C1 / USB-C2 / USB-C3:
PD3.0 / AFC / FCP / SCP / QC2.0 / QC3.0 / QC4+ / PPS
.
USB-A1:
AFC / FCP / QC2.0 / QC3.0
.
Material:
Flame-retardant PC.
Sizes:
102.5 x 93 x 44.5mm.
Cable length:
1.5m.
Weight:
655g.
Certification:
FCC.
Feature 1:
4 charging modes can be switched, the high power of 218W matches the charging power required by different devices.
Feature 2:
Display shows the voltage and charging status of each port in real time.
Feature 3:
The GaN technology is used to improve the overall energy and efficiency. Smaller size and lower temperature charging.
Feature 4:
1.25mm² bold copper wire, high safety factor.
Feature 5:
Suitable for fast charging of devices such as phones / tablets / laptops / game consoles, etc.
Feature 6:
Multiple safety protection.
